TECHNIQUE FOR PLASMA DIAGNOSTICS BASED ON RESONANCE LINES OF NE-LIKE KR XXVII ION AND ITS SATELLITES
- Autores: Skobelev I.Y.1,2, Kulikov R.K.1,2, Ryazantsev S.N.1,2
-
Afiliações:
- Joint Institute for High Temperatures of the Russian Academy of Sciences
- National Research Nuclear University “MEPhI”
- Edição: Volume 51, Nº 3 (2025)
- Páginas: 296-303
- Seção: PLASMA DIAGNOSTICS
- URL: https://rjdentistry.com/0367-2921/article/view/686864
- DOI: https://doi.org/10.31857/S0367292125030042
- EDN: https://elibrary.ru/GAVLXA
- ID: 686864
Citar
Resumo
The X-ray spectral diagnostics of laser plasma of heavy elements that does not contain few-electron ions is considered. The X-ray spectral method for measuring the temperature and density of laser plasma of krypton cluster targets is developed. It is based on analyzing resonance spectral lines of Ne-like krypton ions Kr XXVII and their two-electron satellites arising due to transitions in Na- and Mg-like Kr XXVI and Kr XXV ions. Using the results of the calculations performed, it is possible to determine the ion density of plasma in the range of 1017–1021 cm−3 and the electron temperature in the range of 200–1000 eV. It is shown that one spectrometer with the spherically curved quartz crystal, which has a sufficiently high spectral and spatial resolution, can be used for experimental recording all required diagnostic spectral lines of krypton ions.
Palavras-chave
Sobre autores
I. Skobelev
Joint Institute for High Temperatures of the Russian Academy of Sciences; National Research Nuclear University “MEPhI”
Email: igor.skobelev@gmail.com
Moscow, Russia; Moscow, Russia
R. Kulikov
Joint Institute for High Temperatures of the Russian Academy of Sciences; National Research Nuclear University “MEPhI”
Email: roma.st.2001@gmail.com
Moscow, Russia; Moscow, Russia
S. Ryazantsev
Joint Institute for High Temperatures of the Russian Academy of Sciences; National Research Nuclear University “MEPhI”
Email: ryazantsev@ihed.ras.ru
Moscow, Russia; Moscow, Russia
Bibliografia
- Fortov V.E. and Morfill G.E. Complex and Dusty Plasmas: From Laboratory to Space. CRC Press, 2010.
- Fennel T., Meiwes-Broer K.-H., Tiggesb¨аumker J., Reinhard P.-G., Dinh P.M. and Suraud E. // Rev. Mod. Phys. 2010. V. 82. 1793.
- Ditmire T., Zweiback J., Yanovsky V.P., Cowan T.E., Hays G. and Wharton K.B. // Nature. 1999. V. 398. P. 489
- Grillon G., Balcou Ph., Chambaret J.-P., Hulin D., Martino J., Moustaizis S., Notebaert L., Pittman M., Pussieux Th., Rousse A., Rousseau J-Ph., Sebban S., Sublemontier O. and Schmid M. // Phys. Rev. Lett. 2002. V. 89. 065005.
- Lu H.Y., Liu J.S., Wang C., Wang W.T., Zhou Z.L., Deng A.H., Xia C.Q., Xu Y., Lu X.M., Jiang Y.H., Leng Y.X., Liang X.Y., Ni G.Q., Li R.X. and Xu Z.Z. // Phys. Rev A. 2009. 80. 051201(R)
- Last I., Ron S. and Jortner J. // Phys. Rev. A. 2011. V. 83. 043202. https://doi.org/10.1103/PHYSREVA.83.043202
- Ditmire T., Tisch J.W.G., Springate E., Mason M.B., Hay N., Smith R.A., Marangos J. and Hutchinson M.H.R. // Nature. 1997. V. 386. P. 54. https://doi.org/10.1038/386054a0
- Tajima T., Kishimoto Y. and Downer M.C. // Phys. Of Plasmas. 1999. V. 6. P. 3759.
- Sakabe S., Shimizu S., Hashida M., Sato F., Tsuyukushi T., Nishihara K., Okihara S., Kagawa T., Izawa Y., Imasaki K. and Iida T. // Phys. Rev. A. 2004. V. 69. 023203. http://dx.doi.org/10.1103/PhysRevA.69.023203
- Zhang L., Chen L.-M., Wang W.-M., Yan W.-Ch., Yuan D.-W., Mao J.-Y., Wang Z.-H., Liu Ch., Shen Z.-W., Faenov A., Pikuz T., Li D.-Z., Li Y.-T., Dong Q.-L., Lu X., Ma J.-L., Wei Z.-Y., Sheng Z.-M., Zhang J. // Appl. Phys. Lett. 2012. V. 100. 014104. https://doi.org/10.1063/1.3673911
- Hah J., Nees J.A., Hammig M.D., Krushelnick K. and Thomas A.G.R. // Plasma Phys. Control. Fusion. 2018. V. 60. 054011.
- McPherson A., Thompson B.D., Borisov A.B., Boyer K. and Rhodes C.K. // Nature. 1994. V. 370. P. 631. https://doi.org/10.1038/370631a0
- Donnelly T.D., Ditmire T., Neuman K., Perry M.D. and Falcone R.W. // Phys. Rev. Lett. 1996. V. 76. P. 2472. https://doi.org/10.1103/PhysRevLett.76.2472
- Chu H.-H., Tsai H.-E., Chou M.-C., Yang L.-S., Lin J.-Y., Lee C.-H., Wang J. and Chen S.-Y. // Phys. Rev. A. 2005. V. 71. 061804(R). https://doi.org/10.1103/PhysRevA.71.061804
- Namba S., Hasegawa N., Nagashima K., Kawachi T., Kishimoto M., Sukegawa K. and Takiyama K. // Phys. Rev. A. 2006. V. 73. 013205.
- Kugland N.L., Constantin C.G., Neumayer P., Chung H.-K., Collette A., Dewald E.L., Froula D.H., Glenzer S.H., Kemp A., Kritcher A.L., Ross J.S., Niemann C. // Appl. Phys. Lett. 2008. V. 92. 241504. https://doi.org/10.1063/1.2945795
- Chen L.M., Liu F., Wang W.M., Kando M., Mao J.Y., Zhang L., Ma J.L., Li Y.T., Bulanov S.V., Tajima T. // Phys. Rev. Lett. 2010. V. 104. 215004.
- Hayashi Y., Pirozhkov A.S., Kando M., Fukuda Y., Faenov A., Kawase K., Pikuz T., Nakamura T., Kiriyama H., Okada H. and Bulanov S.V. // Opt. Lett. 2011. V. 36(9). P. 1614.
- Zhang L., Chen L.-M., Yuan D.-W., Yan W.-Ch., Wang Z.-H., Liu Ch., Shen Z.-W., Faenov A., Pikuz T., Skobelev I., Gasilov V., Boldarev A., Mao J.-Y., Li Y.-T., Dong Q.-L., Lu X., Ma J.-L., Wang W.-M., Sheng Z.-M. and Zhang J. // Opt. Express. 2011. V. 19(25). 25812. https://doi.org/10.1364/OE.19.025812
- Chen L.M., Yan W.C., Li D.Z., Hu Z.D., Zhang L., Wang W.M., Hafz N., Mao J.Y., Huang K., Ma Y., Zhao J.R., Ma J.L., Li Y.T., Lu X., Sheng Z.M., Wei Z.Y., Gao J. and Zhang J. // Scientific Reports. 2013. V. 3. P. 1912
- Le´cz Zs., Andreev A. and Hafz N. // Phys. Rev. E. 2020. V. 102. 053205.
- Бойко В.А., Виноградов А.В., Пикуз С.А., Скобелев И.Ю., Фаенов А.Я. Рентгеновская спектроскопия лазерной плазмы. М.: ВИНИТИ, Итоги науки и техники. Радиотехника, 1980. Т. 27.
- Skobelev I.Yu., Faenov A.Ya., Magunov A.I., Pikuz T.A., Boldarev A.S., Gasilov V.A., Abdallach J., Jr., Junkel-Vives G.C., Auguste T., Dobosz S., d’Oliveira P., Hulin S., Monot P., Blasco F., Dorchies F., Caillaud T., Bonte C., Stenz C., Salin F., Loboda P.A., Litvinenko I.A., Popova V.V., Baidin G.V. and Sharkov B.Yu. // J. Exp. Theor. Phys. 2002. V. 94. P. 966. https://doi.org/10.1134/1.1484990
- Jinno S., Fukuda Y., Sakaki H., Yogo A., Kanasaki M., Kondo K., Faenov A.Ya., Skobelev I.Yu., Pikuz T.A., Boldarev A.S. and Gasilov V.A. // Opt. Express. 2013. V. 21. 20656. https://doi.org/10.1364/OE.21.020656
- Бойко В.А., Пальчиков В.Г., Скобелев И.Ю. и Фаенов А.Я., Рентгеновская спектроскопия многозарядных ионов. М.: Энергоатомиздат, 1988
- Khakhalin S.Ya., Dyakin V.M., Faenov A.Ya., Fiedorowicz H., Bartnik A., Parys P., Osterheld A.L., Nilsen J. // J. Opt. Soc. Amer. 1995. B(12). 1203.
- http://spectr-w3.snz.ru/
- Skobelev I.Yu., Ryazantsev S.N., Kulikov R.K. et al. // Photonics. 2023. V. 10(11). P. 1250
- Gu M.F. // Canadian Journal of Physics. 2008. V. 86(5). 675
- Faenov A.Ya., Pikuz S.A., Erko A.I., Bryunetkin B.A., Dyakin V.M., Ivanenkov G.V., Mingaleev A.R., Pikuz T.A., Romanova V.M. and Shelkovenko T.A. // Physica Scripta. 1994. V. 50(4). P. 333
